ASC LINK
ASC link / K0127BB00
availability - Q3 2026
Patented solution that combines the chest ascender and the triple-lock carabiner into one compact unit. This setup provides greater comfort during ascent and ensures easier rope handling. Ideal for safe and comfortable rope ascent.
- ensures a more stable position of the ascender on a harness, so that the ascender does not get in the way or restrict movement
- placement of the ascender close to the attachment point allows faster rope ascent
- elimination of sharp edges prevents strap damage
- allows easy disconnection of the chest and sit parts of the harness
- simple assembly and disassembly with a 3 mm Allen key
- during installation, the ascender is slid onto the carabiner and secured with a retaining screw
- retaining screw is protected against loosening and hidden under the ascender’s safety catch
- when the ascender is removed, the carabiner can be used as an EN 362 connector
- ascender can be replaced on the carabiner with a plastic cover, which is included in the set
- both the ascender and the cover fix the chest strap of the full-body harness in the correct position
- unique serial number for easier traceability and periodic inspection
- For use with ropes of diameter 8 - 13 mm:
- according to EN 12841 ......... with a static rope Ø 10 - 13 mm, max. load 140 kg
- according to EN 567 ............. with a rope Ø 8 - 13 mm
| Color | black matt |
|---|---|
| Weight | 220 g • 7.8 oz |
| Material | light alloy, stainless steel, plastic |
| Strength major axis | 32 kN |
| Strength minor axis | 8 kN |
| Strength open gate | 8 kN |
| Gate opening (d) | 24 mm |
| Max. diameter of rope | 13 mm |
1019
EN 362
EN 567
EN 12841-B
Download
catalogue sheet
PDF - 1,6 MB
Related goods
Activities at height such as climbing, via ferrata, caving, rappelling, ski-touring, rescue, work at height and exploration are dangerous activities, which may lead to severe injury or even death. This the following is essential before use:
careful reading and understanding of the instructions for useacquaintance with the possibilities and limitations of the productadequate apprenticeship in appropriate techniques and methods of useunderstanding and acceptance of the risk involved
In case of doubt or problem of understanding, contact SINGING ROCK.
careful reading and understanding of the instructions for useacquaintance with the possibilities and limitations of the productadequate apprenticeship in appropriate techniques and methods of useunderstanding and acceptance of the risk involved
In case of doubt or problem of understanding, contact SINGING ROCK.
